Name: Performance Evaluation and Certification for Checkweighing Equipment
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Evaluasi Kinerja dan Sertifikasi untuk Peralatan Checkweighing
Availability: InStock

Rumah Produk Timbangan Otomatis

Performance Evaluation and Certification for Checkweighing Equipment

Detail produk:

Tempat asal:	CINA
Nomor model:	Evaluasi Kinerja dan Sertifikasi untuk Peralatan Checkweighing

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kotak Caron
Waktu pengiriman:	10-30 hari
Menyediakan kemampuan:	2000 set per bulan

Kontak

Detil Deskripsi produk

Produk:	Evaluasi Kinerja dan Sertifikasi untuk Peralatan Checkweighing	Toleransi menimbang:	± 0,1-0,5% dari berat target (bervariasi berdasarkan kelas)
Pembagi minimum (e):	E = 1–10g (untuk Kelas III)	Laju throughput:	100–600 unit/menit (tergantung pada kecepatan konveyor)
Waktu stabilisasi:	≤2 detik (untuk penimbangan dinamis)	Frekuensi:	Mingguan (penggunaan tinggi) atau triwulanan (penggunaan rendah)
Kalibrasi otomatis:	Pemicu suhu atau berbasis waktu (jika dilengkapi)	Kisaran suhu:	0 ° C hingga 40 ° C (operasional), -20 ° C hingga 60 ° C (penyimpanan)
Resistensi getaran:	± 0,2g (ISO 10816-3 untuk getaran industri)	Kecepatan Konveyor:	0,1–1,5 m/s (dapat disesuaikan)
Kapasitas kelebihan beban:	120% dari kapasitas maks (batas keamanan)	Kepatuhan EMC:	Tolak mekanisme
Catu daya:	24V DC ± 5% atau 100–240V AC, 50/60Hz	Pengulangan:	± 0,05-0,2% dari berat target (10 tes berturut -turut)
Kesalahan linearitas:	± 0,1-0,3% dari skala penuh	Hukum-untuk-Trade:	NTEP (AS), pertengahan 2014/32/EU (Eropa), OIML R51 (Global)
Keamanan material:	Patuh FDA (jika kontak makanan), Stainless Steel 316	Pencatatan Data:	Timestamp, Weight, Batch ID (Ekspor CSV/PDF)
Tolak mekanisme:	Pneumatik/mekanik (waktu respons ≤100ms)
Menyoroti:	Mettler Toledo load cell checkweighing equipment , checkweighing equipment performance evaluation , certified checkweighing equipment

Performance Evaluation and Certification for Checkweighing Equipment

Performance evaluation and certification for checkweighing equipment is a critical process for ensuring product quality, legal compliance, and operational efficiency. Unlike static scales, checkweighers weigh products in motion, which introduces unique variables that must be carefully managed.

Attribute	Value
Weighing Tolerance	±0.1–0.5% of target weight (varies by class)
Minimum Divisor (e)	e = 1–10g (for Class III)
Throughput Rate	100–600 units/minute (depends on conveyor speed)
Stabilization Time	≤2 seconds (for dynamic weighing)
Frequency	Weekly (high-use) or Quarterly (low-use)
Auto-Calibration	Temperature-triggered or time-based (if equipped)
Temperature Range	0°C to 40°C (operational), -20°C to 60°C (storage)
Vibration Resistance	±0.2g (ISO 10816-3 for industrial vibration)
Conveyor Speed	0.1–1.5 m/s (adjustable)
Overload Capacity	120% of max capacity (safety limit)
EMC Compliance	Reject Mechanism
Power Supply	24V DC ±5% or 100–240V AC, 50/60Hz
Repeatability	±0.05–0.2% of target weight (10 consecutive tests)
Linearity Error	±0.1–0.3% of full scale
Legal-for-Trade	NTEP (US), MID 2014/32/EU (Europe), OIML R51 (Global)
Material Safety	FDA-compliant (if food contact), Stainless Steel 316
Data Logging	Timestamp, weight, batch ID (CSV/PDF export)
Reject Mechanism	Pneumatic/mechanical (response time ≤100ms)

Key Components of Performance Evaluation

1. Initial Assessment and Mechanical Inspection

Before any tests begin, a thorough physical inspection is necessary to ensure the checkweigher's fundamental components are in good working order and not causing measurement errors.

Visual Check: Inspect the conveyor belts, weigh platform, and frame for any signs of damage, wear, or debris. The weigh platform must be free-floating and not touching any surrounding parts.
Component Integrity: Check for loose bolts, screws, or wiring. The load cell, which is the heart of the weighing system, must be secure and undamaged.
Environmental Factors: The checkweigher's performance is sensitive to its environment. Factors like vibration from other machinery, temperature, and humidity can all affect accuracy.

2. Calibration and Verification

Calibration adjusts the checkweigher to ensure correct measurements, while verification confirms the system's accuracy and consistency.

Static Calibration: Preliminary calibration with certified test weights while the conveyor is stopped to establish baseline accuracy.
Dynamic Calibration: Crucial test where a known product is passed over the moving conveyor multiple times to confirm motion weighing accuracy.
Repeatability Test: A single product of known weight is run through multiple times to check consistency within tight tolerances.
Corner Load Test: Weight is placed at different corners of the weigh platform to verify performance of all load cells.
