Name: Checkweighers in Logistics and Shipping
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Penimbang Cek Multifungsi dengan Kombinasi Berat, Deteksi Logam, dan Pemeriksaan Sinar X
Availability: InStock

Rumah Produk Timbangan Otomatis

Checkweighers in Logistics and Shipping

Detail produk:

Tempat asal:	CINA
Nomor model:	Penimbang Cek Multifungsi dengan Kombinasi Berat, Deteksi Logam, dan Pemeriksaan Sinar X

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kotak Caron
Waktu pengiriman:	10-30 hari
Menyediakan kemampuan:	2000 set per bulan

Kontak

Detil Deskripsi produk

Produk:	Checkweighers dalam logistik dan pengiriman	Rentang Kapasitas:	50g - 300kg
Ketepatan:	± 0,1% atau ± 5g (mana yang lebih besar)	Kecepatan berat:	0,3–2 detik per item
Akurasi volumetrik:	± 5mm L/W/H.	Tinggi pemindaian:	50–1000mm
Lebar Konveyor:	400–1200mm	Ukuran paket maks:	1200 × 800 × 800mm
Tipe Sabuk:	Pu-coed, gesekan tinggi	Protokol Komunikasi:	REST API, JSON, XML
Tipe barcode:	1d/2d, qr, rfid	Output data:	Latensi 10–100ms
Suhu Operasional:	-10 ° C hingga +50 ° C.	Resistensi kelembaban:	10–95% non-kondensasi
Hukum-untuk-Trade:	NTEP, pertengahan 2014/32/EU	Standar Keamanan:	UL 61010-1, CE
AUTO-TARE:	Bobot wadah preset 10–50kg	Penimbangan dinamis:	Kecepatan sabuk 0,5-5m/menit
Perlindungan Kelebihan Beban:	150% kapasitas
Menyoroti:	Mettler Toledo load cell weighing inspection , manufacturing weighing inspection techniques , logistics load cell weighing solutions

Checkweighers in Logistics and Shipping

Attribute	Value
Capacity Range	50g – 300kg
Accuracy	±0.1% or ±5g (whichever is greater)
Weighing Speed	0.3–2 seconds per item
Volumetric Accuracy	±5mm L/W/H
Scanning Height	50–1000mm
Conveyor Width	400–1200mm
Max Package Size	1200800800mm
Belt Type	PU-coated, high-friction
Communication Protocols	REST API, JSON, XML
Barcode Types	1D/2D, QR, RFID
Data Output	10–100ms latency
Operating Temperature	-10°C to +50°C
Humidity Resistance	10–95% non-condensing
Legal-for-Trade	NTEP, MID 2014/32/EU
Safety Standards	UL 61010-1, CE
Auto-Tare	10–50kg preset container weights
Dynamic Weighing	0.5–5m/min belt speed
Overload Protection	150% of capacity

Introduction to Logistics Checkweighing

Checkweighers in logistics and shipping operations serve as critical quality control and cost management tools, ensuring:

Accurate freight billing (prevents revenue loss from under/overcharging)
Regulatory compliance (meets trade laws and carrier requirements)
Package integrity verification (detects missing items or incorrect shipments)
Automated sorting (diverts non-compliant parcels pre-shipment)

With e-commerce growth, modern systems now handle 50-1,000+ packages/hour while integrating with warehouse management systems (WMS).

System Types for Logistics

In-Motion Checkweighers

Throughput: 300-1,200 parcels/hour
Applications:
- E-commerce fulfillment centers (diverts underweight shipments missing items)
- Postal sorting hubs (verifies postage-paid weight classes)

Static Dimensioning Scales

Accuracy: ±0.05% for freight billing
Features:
- Pallet weighing with corner load compensation
- Over-dimension alerts for carrier restrictions

Mobile Checkweighing Stations

Portable units with battery operation
Used for:
- Loading dock verification
- Cross-docking QC checks

Modern logistics checkweighers have evolved into smart shipping hubs, combining precision weighing, automated sorting, and carrier compliance in one system. Proper implementation typically pays for itself in 3-9 months through freight savings alone.
