Name: 5kg MT1022 Load Cell with 1m Cable – Ideal for Weighing Systems
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Load Cell MT1022-5kg 1M
Availability: InStock

Rumah Produk

5kg MT1022 Load Cell with 1m Cable – Ideal for Weighing Systems

Detail produk:

Tempat asal:	Cina
Nama merek:	Mettler Toledo
Nomor model:	Load Cell MT1022-5kg 1M

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	kotak karon
Waktu pengiriman:	10-30 hari
Menyediakan kemampuan:	2000 ditetapkan per bulan

Kontak

Detil Deskripsi produk

produk:	Sel beban Mettler Toledo	Kapasitas maksimum:	11 lb (5 kg)
Bahan:	Aluminium, pasif	metrologi:	NTEP III 5.000D OIML C3
Keakuratan:	Standar	Peringkat perlindungan:	IP67
Ukuran Platform (LXW):	350 mm x 350 mm	Konektivitas:	Analog
kabel:	PVC
Menyoroti:	5kg MT1022 load cell , load cell with 1m cable , Mettler Toledo weighing system

5kg MT1022 Load Cell with 1m Cable – Ideal for Weighing Systems

Product Overview

A high-performance compression weigh module designed for precise measurement in industrial weighing applications. The MT1022 load cell features a top plate and base plate that compress under weight, allowing direct attachment to ground, piers, or structural beams. Ideal for platform scales, tank weighing, and hopper/silo applications with capacities ranging from 3 kg to 300 tons.

Key Features

Accuracy

High-performance single point load cell with off-center compensation for platform moments. Includes OIML metrology approvals as standard.

Reliable Strain Gage Technology

Manufactured with premium aluminum materials and advanced strain gage technology for exceptional long-term durability.

Hazardous Area Usage

Includes ATEX Zone 1/21/2/22 approvals as standard - no need for special options or variations.

Technical Specifications

Product	Mettler Toledo Load Cell
Maximum Capacity	11 lb (5 kg)
Material	Aluminum, passivated
Material No	71201826
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	350 mm x 350 mm
Connectivity	Analog
Cable	PVC

Applications

Small platform scales
Industrial weighing systems
Tank, hopper and silo weighing
Hazardous area installations
Precision measurement applications
