Name: 2200kg SWB405 Weighing Module – Heavy-Duty Carbon Steel Load Cell with 5m Cable
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Modul Berat SWB405 2200kg 5m CS
Availability: InStock

Rumah Produk

2200kg SWB405 Weighing Module – Heavy-Duty Carbon Steel Load Cell with 5m Cable

Detail produk:

Tempat asal:	Cina
Nama merek:	Mettler Toledo
Nomor model:	Modul Berat SWB405 2200kg 5m CS

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	kotak karon
Waktu pengiriman:	10-30 hari
Menyediakan kemampuan:	2000 ditetapkan per bulan

Kontak

Detil Deskripsi produk

produk:	Sel beban Mettler Toledo	Kapasitas maksimum:	5.000 lb (2.200 kg)
Bahan:	baja karbon berlapis bubuk	metrologi:	OIML C3, NTEP III 5M
Muat sel:	SLB415	Keakuratan:	Standar
Peringkat perlindungan:	IP68, NEMA 6	Lingkungan / material:	Baja normal / karbon
Persetujuan Berbahaya:	ATEX, FM	KRIMITAS:	Standar
kabel:	5 M
Menyoroti:	2200kg heavy-duty load cell , carbon steel weighing module , Mettler Toledo load cell with cable

2200kg SWB405 Weighing Module – Heavy-Duty Carbon Steel Load Cell with 5m Cable

Product Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	5,000 lb (2,200 kg)
Material	Powder Coated Carbon Steel
Metrology	OIML C3, NTEP III 5M
Load Cell	SLB415
Accuracy	Standard
Protection Rating	IP68, NEMA 6
Environment / Material	Normal / Carbon Steel
Hazardous Approval	ATEX, FM
Criticality	Standard
Cable	5 m

Product Description

A compression weigh module is designed so that its top plate and base plate will be squeezed toward each other when weight is applied to it, and it can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales and in tank, hopper and silo weighing. Capacities for compression load cells, which are within compression weigh modules, range from 3 kg to 300 tons.

Key Features

All Safety on Board: Offers all safety features, including anti-uplift protection, 360° checking and down-stop protection to ensure the safety of tank weighing.
Easy Integration: SafeLock™ feature is built into SWB405 MultiMount™ weigh modules to make installation easier with all components locked in ideal initial positions.
Reliable Weighing: The hermetically sealed SLB415 load cell with IP68 rating can meet most industrial requirements.

Technical Specifications

Material

Powder Coated Carbon Steel

Material No

30830614

Maximum Capacity

5,000 lb (2,200 kg)

Protection Rating

IP68, NEMA 6

Environment / Material

Normal / Carbon Steel

Hazardous Approval

ATEX, FM

Load Cell

SLB415

Accuracy

Standard

Metrology

OIML C3, NTEP III 5M
